The Wireless Door/Window magnetic contact is perfectly poised to protect every potential point of entry,which can be installed on doors, windows and many other objects that open and close. it comprises of a magnet and a transmitter,transmitter will transmit signals to the control panel when the magnet mounted near the sensor is moved away from or closer to the transmitter. with an average range of 100m(open space),this easy-to-install mechanism makes a reliable,convenient and cost-effective solution for any home or commercial property.
-With Test&Panic button
-Built long-life 200mAh 3.7V rechargeable lithium battery(more than 1 year life time)
-Internal antenna design
-Up to 100m working range
1. Power: 200mAh 3.7V rechargeable lithium battery
2. Frequency: FSK868MHZ
3. Distance: <100m ( Outdoor, open space)
4. Operating temperature: -10°C~50°C (14°F ~122°F)
5. Operating humidity: 30°C±2 ≤85%±5
6. Storage and transport temperature: -40°C~55°C (-40°F~131°F)
7. Storage and transport humidity: 40°C≤90%
8. Magnetic gap (Open to Close): <20mm
9. Magnetic gap (Close to Open): <20mm
Note:If you're not sure if the sensor is suitable for your existing system, please feel free to contact us.
What is in the package?
1x Wireless 868mhz contact sensor(magnetic switch)
How to install the Door/window magnetic contact?
1.The magnetic contact can be mounted by simply sticking using the included double-side adhesive strip(s) or screws.
2.Find the right location that you want to install the magnetic contact, Flat and smooth surfaces are ideal,Make sure they are clean and dry before mounting.
3.Peel off one side of the adhesive strip and attach it to the rear of the magnet and transmitter backing plate , ensuring none of it is visible from the front.
4.Peel off the other side of the adhesive strip and attach the magnet and transmitter to the mounting surface.
5.Press the Test&Panic button to make sure that it is within the control panel response range.
1)Ensure that the two parts are opposite each other and a small gap has been left,the gap between two parts should be less than 1cm.
2)Try to mount it as far away from the ground as possible to avoid damaging,and mounting the sensors at a higher position will result in longer working range.
3)Do not mount it to the exterior of the door or window, but always to the interior side to avoid being damaged.
4)If you have children, please install it out of their reach.
